31. Unlock the four clips with a slotted screwdriver.
32. Turn around the D-COVER and unlock the last clip.
Reassembly instructions (upper block)
Steps
1. Follow the disassembly instructions
in reversed order
, from step 32 to step 13.
Note: Pay special attention to step 19.
2. Mind the correct positioning of the CAMERA MODULE.
RM-70
Nokia Customer Care Disassembly and reassembly instructions
Page 5 –18 COMPANY CONFIDENTIAL Issue 1
Copyright © 2005 Nokia. All rights reserved.
