Page #44 background imageLoading...
Page #44 background image
Item Name PWB side X Y Value
Z6030 LTCC FILT 2441.75+-41.75MHZ 2.5X2 Bottom O 2 2441.75MHz
Z7001 PHASE SHIFTER GSM1800/1900 TX TDK Bottom D 7 1800/1900M
Hz
Z7002 PHASE SHIFTER GSM1800/1900 TX TDK Bottom D 7 1800/1900M
Hz
Z7501 DUAL RX SAW FILTER 1800/1900MHZ 2016 Top G 6 1800/1900M
Hz
Z7503 TX SAW MODULE GSM 850/900MHZ 4.5X3.2 Top I 6 850/900MHz
Z7504 DUAL RX SAW FILTER 850/900MHZ 2016 Top H 6 850/900MHz
Z7520 FERRITE BEAD 0R01 28R/100MHZ 0603 Top G 6 28R/100MHz
Non replaceable parts
These parts must not be replaced:
No. Name Comment
1 RAP GSM
2 VCO Placed under shielding and is therefore critical and difficult to replace.
3 Module ID
component
Only used in production.
RM-70
Nokia Customer Care Parts and layouts
Page 2 –22 COMPANY CONFIDENTIAL Issue 1
Copyright © 2005 Nokia. All rights reserved.
