Nokia RM-70 User Manual

Region Colour
TR Coffee Brown
UA Warm Amber
UA Coffee Brown
Component parts list
Table 8 Component parts list (PWB 1lua_50a)
Item Name PWB side X Y Value
A2400 RETU-TAHVO ASSEMBLY 040-009341 P2465 Top L 7 ~
A2800 RAP ASSEMBLY 040-009340 P2465 Top L 3 ~
A3300 HWA ASSEMBLY 040-009339 P2465 Bottom H 4 ~
A6150 BT ASSEMBLY 040-009338 P2465 Bottom O 4 ~
A7000 RF ASSEMBLY 040-009342 P2465 Top H 5 ~
B2200 CRYSTAL 32.768KHZ +-20PPM 12.5PF Top N 7 32.768kHz
C2000 Chipcap 5% NP0 Bottom P 4 27p
C2001 Chipcap X7R 10% 50V 0402 Bottom P 4 1n0
C2002 CHIPCAP X5R 2U2 K 6V3 0603 Top P 6 2u2
C2003 CHIPCAP X7R 33N K 10V 0402 Top P 6 33n
C2004 CHIPCAP X7R 33N K 10V 0402 Top P 6 33n
C2005 Chipcap X7R 10% 16V 0402 Top P 6 10n
C2006 Chipcap X7R 10% 16V 0402 Top P 6 10n
C2007 Chipcap X7R 10% 16V 0402 Top P 7 10n
C2008 Chipcap X7R 10% 16V 0402 Top P 7 10n
C2009 Chipcap X7R 10% 16V 0402 Top P 7 10n
C2010 Chipcap X7R 10% 16V 0402 Top P 7 10n
C2011 Chipcap 5% NP0 Top P 7 10p
C2012 Chipcap 5% NP0 Top P 7 10p
C2013 Chipcap 5% NP0 Top P 7 10p
C2014 Chipcap 5% NP0 Top P 7 10p
C2015 CHIPCAP X5R 100N K 10V 0402 Top P 6 100n
C2016 CHIPCAP NP0 270P J 25V 0402 Bottom P 5 270p
C2017 CHIPCAP X5R 470N K 25V 0603 Bottom Q 4 470n
C2018 Chipcap X7R 10% 16V 0402 Bottom P 5 10n
C2019 Chipcap X7R 10% 16V 0402 Bottom P 6 10n
C2020 Chipcap X7R 10% 16V 0402 Top O 8 10n
C2070 CHIPTCAP 150U M 10V 6X3.2X1.5 Bottom E 8 150u_10V
RM-70
Parts and layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –9
Copyright © 2005 Nokia. All rights reserved.
