Nokia RM-70 User Manual

Item Name PWB side X Y Value
C2071 Chipcap 5% NP0 Bottom H 7 27p
C2072 Chipcap 5% NP0 Top O 6 27p
C2073 CHIPCAP X5R 1U K 6V3 0603 Bottom H 8 1u0
C2074 Chipcap X7R 10% 16V 0402 Bottom G 8 10n
C2075 CHIPCAP X5R 1U K 6V3 0603 Bottom H 7 1u0
C2076 Chipcap X7R 10% 16V 0402 Bottom H 7 10n
C2077 Chipcap X7R 10% 16V 0402 Bottom H 6 10n
C2078 Chipcap 5% NP0 Bottom E 8 27p
C2079 Chipcap 5% NP0 Bottom H 8 27p
C2100 CHIPCAP X7R 33N K 10V 0402 Top P 8 33n
C2101 CHIPCAP X7R 33N K 10V 0402 Top P 7 33n
C2102 CHIPCAP X5R 2U2 K 6V3 0603 Top P 8 2u2
C2103 Chipcap X7R 10% 50V 0402 Top O 7 1n0
C2104 Chipcap X7R 10% 50V 0402 Top O 7 1n0
C2105 Chipcap 5% NP0 Bottom H 6 27p
C2106 Chipcap 5% NP0 Bottom G 6 27p
C2107 Chipcap 5% NP0 Top G 8 27p
C2108 Chipcap X7R 10% 50V 0402 Bottom K 9 1n0
C2109 Chipcap X7R 10% 50V 0402 Bottom K 9 1n0
C2110 Chipcap X7R 10% 50V 0402 Bottom K 9 1n0
C2111 Chipcap 5% NP0 Top F 5 27p
C2112 Chipcap X7R 10% 50V 0402 Bottom K 8 1n0
C2113 Chipcap X7R 10% 50V 0402 Bottom K 9 1n0
C2114 Chipcap X7R 10% 50V 0402 Bottom K 9 1n0
C2117 CHIPCAP X5R 100N K 10V 0402 Bottom N 9 100n
C2118 CHIPCAP X5R 100N K 10V 0402 Bottom M 9 100n
C2119 CHIPCAP X5R 100N K 10V 0402 Bottom N 9 100n
C2120 CHIPCAP X5R 100N K 10V 0402 Bottom N 9 100n
C2124 CHIPCAP X5R 100N K 10V 0402 Bottom L 9 100n
C2126 CHIPCAP X5R 10U M 6V3 0805 Bottom L 9 10U
C2127 CHIPCAP X5R 1U K 6V3 0603 Bottom M 9 1u0
C2200 CHIPCAP X5R 1U K 6V3 0603 Top M 6 1u0
C2201 CHIPCAP X5R 1U K 6V3 0603 Top M 8 1u0
C2202 Chipcap X7R 10% 50V 0402 Top N 9 1n0
C2203 Chipcap X7R 10% 50V 0402 Top N 7 1n0
RM-70
Nokia Customer Care Parts and layouts
Page 2 –10 COMPANY CONFIDENTIAL Issue 1
Copyright © 2005 Nokia. All rights reserved.
