Nokia RM-70 User Manual

Item Name PWB side X Y Value
C2204 Chipcap X7R 10% 50V 0402 Top N 7 1n0
C2205 Chipcap X7R 10% 50V 0402 Top N 6 1n0
C2206 Chipcap X7R 10% 50V 0402 Top N 7 1n0
C2207 Chipcap X7R 10% 50V 0402 Top N 8 1n0
C2208 Chipcap 5% NP0 Top N 7 27p
C2209 Chipcap 5% NP0 Top N 7 22p
C2210 CHIPCAP X5R 1U K 16V 0603 Top L 8 1u0
C2211 CHIPCAP X5R 4U7 K 10V 0805 Top L 8 4u7
C2212 CHIPCAP X5R 1U5 K 4V 0402 Top L 7 1u5
C2213 CHIPCAP X5R 1U5 K 4V 0402 Top M 8 1u5
C2214 CHIPCAP X5R 1U5 K 4V 0402 Top M 8 1u5
C2215 CHIPCAP X5R 1U5 K 4V 0402 Top M 8 1u5
C2216 CHIPCAP X5R 1U5 K 4V 0402 Top L 8 1u5
C2217 CHIPCAP X5R 1U5 K 4V 0402 Top N 8 1u5
C2218 Chipcap X7R 10% 50V 0402 Top N 7 1n0
C2219 CHIPCAP X5R 1U5 K 4V 0402 Top N 8 1u5
C2220 CHIPCAP X5R 1U5 K 4V 0402 Top L 7 1u5
C2221 CHIPCAP X5R 1U K 6V3 0603 Top L 9 1u0
C2222 CHIPCAP X5R 1U K 6V3 0603 Top L 8 1u0
C2223 Chipcap X7R 10% 16V 0402 Top L 6 10n
C2224 Chipcap X7R 10% 16V 0402 Top N 6 10n
C2225 CHIPCAP X5R 1U K 6V3 0603 Top N 8 1u0
C2226 CHIPCAP X5R 1U K 6V3 0603 Top M 8 1u0
C2227 CHIPCAP X5R 1U K 6V3 0603 Top L 7 1u0
C2228 CHIPCAP X5R 1U K 6V3 0603 Top M 8 1u0
C2229 Chipcap X7R 10% 50V 0402 Top L 7 1n0
C2230 CHIPCAP X5R 1U K 6V3 0603 Top N 8 1u0
C2231 CHIPCAP X5R 10U M 6V3 0805 Top L 6 10U
C2232 CHIPCAP X5R 1U K 6V3 0603 Top L 8 1u0
C2273 Chipcap X7R 10% 50V 0402 Top L 6 1n0
C2274 Chipcap X7R 10% 50V 0402 Top L 7 1n0
C2275 Chipcap X7R 10% 50V 0402 Top L 6 1n0
C2281 CHIPCAP X5R 1U K 6V3 0603 Top M 8 1u0
C2300 Chipcap X7R 10% 16V 0402 Top J 6 10n
C2301 CHIPCAP X5R 22U M 6V3 0805 Top J 6 22u
RM-70
Parts and layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –11
Copyright © 2005 Nokia. All rights reserved.
