2. Pay attention to the right length of the COAX CABLE and place the marking at the edge of the SCREWING
PLATE.
3. Follow the disassembly instructions
in reversed order
, from step 16 to step 1.
Note: Pay special attention to step 16.
Disassembly instructions (lower block)
Steps
1. Always protect all windows with a plastic film.
2. Remove the E-COVER.
RM-70
Nokia Customer Care Disassembly and reassembly instructions
Page 5 –10 COMPANY CONFIDENTIAL Issue 1
Copyright © 2005 Nokia. All rights reserved.
