Item Name PWB side X Y Value
C2302 CHIPCAP X5R 22U M 6V3 0805 Top L 6 22u
C2303 CHIPCAP X5R 1U K 6V3 0603 Top J 8 1u0
C2304 Chipcap X7R 10% 16V 0402 Top L 7 10n
C2305 CHIPCAP X5R 1U K 6V3 0603 Top J 9 1u0
C2306 CHIPCAP X5R 1U K 6V3 0603 Top I 9 1u0
C2307 CHIPCAP X5R 1U K 6V3 0603 Top J 7 1u0
C2309 CHIPCAP X5R 22U M 6V3 0805 Top J 6 22u
C2312 CHIPCAP X5R 1U K 6V3 0603 Top J 7 1u0
C2313 CHIPCAP X5R 1U K 6V3 0603 Top J 7 1u0
C2314 CHIPCAP X5R 4U7 K 25V 0805 Top K 8 4u7
C2315 CHIPCAP X5R 4U7 K 25V 0805 Top K 9 4u7
C2400 Chipcap 5% NP0 Bottom K 7 22p
C2401 Chipcap 5% NP0 Bottom J 7 22p
C2402 Chipcap 5% NP0 Top P 5 27p
C2403 Chipcap 5% NP0 Bottom J 8 47p
C2404 Chipcap X7R 10% 25V 0402 Bottom I 7 4n7
C2405 CHIPCAP X5R 100N K 10V 0402 Bottom I 7 100n
C2406 CHIPCAP X5R 100N K 10V 0402 Bottom I 7 100n
C2407 CHIPCAP X5R 100N K 10V 0402 Bottom I 7 100n
C2408 Chipcap 5% NP0 Bottom H 7 27p
C2409 Chipcap X7R 10% 25V 0402 Top Q 3 4n7
C2410 CHIPCAP X5R 100N K 10V 0402 Top Q 4 100n
C2413 Chipcap 5% NP0 Bottom H 6 27p
C2414 Chipcap 5% NP0 Bottom I 7 27p
C2415 Chipcap 5% NP0 Top Q 4 27p
C2416 Chipcap 5% NP0 Top Q 5 27p
C2418 Chipcap 5% NP0 Bottom K 3 22p
C2419 Chipcap 5% NP0 Bottom J 3 22p
C2420 CHIP ARRAY C0G 4X22P K 16V 0612 Bottom J 4 4x22p
C2700 CHIPCAP X5R 100N K 10V 0402 Bottom L 2 100n
C2701 Chipcap 5% NP0 Bottom L 2 27p
C2800 CHIPCAP X5R 100N M 16V 0402 Top L 5 100n
C2801 CHIPCAP X5R 100N M 16V 0402 Top J 4 100n
C2802 CHIPCAP X5R 100N M 16V 0402 Top K 5 100n
C2803 CHIPCAP X5R 100N M 16V 0402 Top L 5 100n
RM-70
Nokia Customer Care Parts and layouts
Page 2 –12 COMPANY CONFIDENTIAL Issue 1
Copyright © 2005 Nokia. All rights reserved.
