Item Name PWB side X Y Value
C2804 CHIPCAP X5R 100N M 16V 0402 Top J 5 100n
C2805 CHIPCAP X5R 100N M 16V 0402 Top M 2 100n
C2807 CHIPCAP X5R 1U K 6V3 0603 Top J 5 1u0
C2808 CHIPCAP X5R 100N M 16V 0402 Top J 5 100n
C2809 CHIPCAP X5R 100N M 16V 0402 Top K 5 100n
C2810 CHIPCAP X5R 100N M 16V 0402 Top L 5 100n
C2811 CHIPCAP X5R 100N M 16V 0402 Top M 2 100n
C2812 CHIPCAP X5R 100N M 16V 0402 Top K 5 100n
C2813 CHIPCAP X5R 100N M 16V 0402 Top J 2 100n
C2814 CHIPCAP X5R 100N M 16V 0402 Top J 5 100n
C2815 CHIPCAP X5R 100N M 16V 0402 Top L 5 100n
C2816 Chipcap 5% NP0 Top M 5 27p
C2818 CHIPCAP X5R 100N M 16V 0402 Top M 3 100n
C2819 CHIPCAP X5R 100N M 16V 0402 Top M 4 100n
C2820 CHIPCAP X5R 100N M 16V 0402 Top J 3 100n
C2821 Chipcap 5% NP0 Top J 3 27p
C2830 Chipcap X7R 10% 50V 0402 Top J 4 1n0
C2831 Chipcap +-0.25pF NP0 Top J 4 4p7
C3000 CHIPCAP X5R 100N M 16V 0402 Top N 2 100n
C3001 Chipcap X7R 10% 16V 0402 Top N 2 10n
C3002 CHIPCAP X5R 100N M 16V 0402 Top N 2 100n
C3003 Chipcap X7R 10% 16V 0402 Top M 5 10n
C3004 CHIPCAP X5R 100N M 16V 0402 Top M 5 100n
C3005 CHIPCAP X5R 100N M 16V 0402 Top N 5 100n
C3006 CHIPCAP X5R 100N M 16V 0402 Top N 5 100n
C3007 Chipcap X7R 10% 16V 0402 Top N 5 10n
C3008 CHIPCAP X5R 100N M 16V 0402 Top M 5 100n
C3009 CHIPCAP X5R 100N M 16V 0402 Top N 5 100n
C3100 Chipcap 5% NP0 Bottom K 6 27p
C3300 CHIPCAP X5R 100N K 10V 0402 Bottom I 4 100n
C3301 CHIPCAP X5R 100N K 10V 0402 Bottom H 4 100n
C3302 Chipcap X5R 10% 6.3V 0402 Bottom G 4 220n
C3303 CHIPCAP X5R 100N K 10V 0402 Bottom I 4 100n
C3304 Chipcap X7R 10% 16V 0402 Bottom I 4 10n
C3305 CHIPCAP X5R 4U7 K 6V3 0603 Bottom I 4 4u7
RM-70
Parts and layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –13
Copyright © 2005 Nokia. All rights reserved.
