Item Name PWB side X Y Value
C3306 CHIPCAP X5R 4U7 K 6V3 0603 Bottom I 4 4u7
C3307 CHIPCAP X5R 10UF 6V3 0603 Bottom I 4 10u
C3308 CHIPCAP X5R 1U K 6V3 0402 Bottom H 4 1u0
C3309 Chipcap 5% NP0 Bottom H 4 27p
C3310 Chipcap 5% NP0 Bottom I 4 27p
C6001 Chipcap +-0.25pF NP0 Top P 3 4p7
C6002 CHIPCAP NP0 0P5 C 50V 0402 Top P 3 0p5
C6010 Chipcap 5% NP0 Bottom M 2 22p
C6011 Chipcap X7R 10% 16V 0402 Bottom L 2 10n
C6012 Chipcap X7R 10% 16V 0402 Bottom M 2 10n
C6031 Chipcap 5% NP0 Bottom O 2 18p
C6032 Chipcap 5% NP0 Bottom P 4 100p
C6033 Chipcap X7R 10% 16V 0402 Bottom P 3 10n
C6034 Chipcap X7R 10% 16V 0402 Bottom P 3 10n
C6035 Chipcap X7R 10% 16V 0402 Bottom O 3 10n
C6036 Chipcap X7R 10% 16V 0402 Bottom O 4 10n
C6037 CHIPCAP X5R 1U K 6V3 0402 Bottom O 4 1u0
C6039 Chipcap 5% NP0 Bottom P 3 18p
C6040 CHIPCAP X5R 1U K 6V3 0402 Bottom O 4 1u0
C6041 CHIPCAP X5R 1U K 6V3 0603 Bottom P 3 1u0
C6042 Chipcap X7R 10% 16V 0402 Bottom O 3 10n
C6051 Chipcap +-0.25pF NP0 Bottom O 3 2p7
C6052 Chipcap +-0.25pF NP0 Bottom P 3 2p7
C6157 Chipcap X7R 10% 16V 0402 Bottom O 6 10n
C6158 CHIPCAP X5R 100N K 10V 0402 Bottom O 6 100n
C6159 CHIPCAP X7R 33N K 10V 0402 Bottom O 4 33n
C6162 CHIPCAP X7R 33N K 10V 0402 Bottom O 6 33n
C6163 CHIPCAP X7R 33N K 10V 0402 Bottom P 5 33n
C6164 CHIPCAP X5R 100N K 10V 0402 Bottom O 5 100n
C6165 CHIPCAP X7R 33N K 10V 0402 Bottom O 4 33n
C6167 Chipcap X7R 10% 16V 0402 Bottom P 5 10n
C6170 Chipcap X7R 10% 16V 0402 Bottom P 5 10n
C6176 Chipcap 5% NP0 Bottom P 4 100p
C6178 Chipcap 5% NP0 Bottom P 5 27p
C6179 Chipcap 5% NP0 Bottom P 5 47p
RM-70
Nokia Customer Care Parts and layouts
Page 2 –14 COMPANY CONFIDENTIAL Issue 1
Copyright © 2005 Nokia. All rights reserved.
