Item Name PWB side X Y Value
R7505 CHIPRES 0W06 8K2 F 0402 Top H 3 8k2
R7506 Resistor 5% 63mW Top H 4 10R
R7507 Resistor 5% 63mW Top G 4 10R
R7508 Resistor 5% 63mW Top H 3 10R
R7509 Resistor 5% 63mW Top I 3 22k
R7510 Resistor 5% 63mW Top I 7 15R
R7522 CHIPRES 0W06 27K F 0402 Top I 7 27k
R7523 Chipres 0W06 jumper 0402 Top G 7 0R
S2401 SM SW TACT SPST 12V 50MA SIDE KEY Bottom H 2 ~
S2402 SM SW TACT SPST 12V 50MA SIDE KEY Bottom J 2 ~
S2403 SM SW TACT SPST 12V 50MA SIDE KEY Bottom I 9 ~
S2404 SM SW TACT SPST 12V 50MA SIDE KEY Bottom O 9 ~
T7501 TRANSF BALUN 3800+-550MHZ 0805 Top H 3 ~
T7520 TRANSF BALUN 1800+-100mhz 2x1.25 Top G 8 ~
V2000 ASIP TVS BGA4 Bottom P 4 ~
V2001 TR DTC143ZM N RB=4K7 RBE=47K VMT3 Top O 6 ~
V2302 SCH DI 30V 2A SOD323F Top I 8 ~
V2401 TRX2 BIPOLAR 2XPNP 40V 0A1 0W12 SOT666 Top P 9 ~
V2402 TR DTC143ZM N RB=4K7 RBE=47K VMT3 Top O 9 ~
V6010 Tr NPN 12V 35mA SOT323 Bottom M 2 ~
X2000 CONN DC-JACK 2.0MM 3POL SPR 90DEG Bottom Q 3 ~
X2001 SM SYSTEM CONNECTOR 14POL Bottom Q 6 ~
X2060 MODULE ID COMPONENT 2.8X1.8X0.3 Bottom H 6 ~
X2070 CONN BATT 3.5V 2A P3.7 H4.5MM Bottom G 7 ~
X2400 SM CONN 20P P0.47 PWB/PWB Top P 4 ~
X2402 SM B2B 2X17 P0.4 F 30V 0.3A FEMALE Bottom I 8 ~
X2700 SM SIM CONN 11POL H2.0 Bottom M 5 ~
X3300 SMIA85 SOCKET Bottom F 3 ~
X7000 SM CONN RF JACK 50R 2W 6GHZ Bottom E 7 ~
Z2000 FERRITE BEAD 0.6R 600R/100MHZ 0402 Bottom Q 5 600R/
100MHz
Z2001 FERRITE BEAD 0.6R 600R/100MHZ 0402 Bottom Q 6 600R/
100MHz
Z2003 FERRITE BEAD 0.6R 600R/100MHZ 0402 Bottom Q 5 600R/
100MHz
Z2400 ASIP 10-CH ESD EMI FILTER BGA25 Top O 3 ~
RM-70
Parts and layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –21
Copyright © 2005 Nokia. All rights reserved.
