Item Name PWB side X Y Value
R2421 Resistor 5% 63mW Bottom K 8 33R
R2700 ASIP SIM INTERFACE **LOW CAP**BGA8 Bottom K 5 ~
R2701 CHIPRES JUMPER 0603 Bottom L 2 0R
R2801 Chipres 0W06 jumper 0402 Top K 5 0R
R2803 Resistor 5% 63mW Top L 5 100R
R2804 Resistor 5% 63mW Top L 5 100R
R3000 Resistor 5% 63mW Top M 2 4k7
R3002 Chipres 0W06 jumper 0402 Top K 5 0R
R3003 Resistor 5% 63mW Top M 3 4k7
R3004 Resistor 5% 63mW Top M 4 4k7
R3300 Resistor 5% 63mW Bottom H 3 4k7
R3301 Resistor 5% 63mW Bottom H 3 4k7
R3306 Resistor 5% 63mW Bottom H 3 100R
R3307 Resistor 5% 63mW Bottom H 3 100R
R3312 Resistor 5% 63mW Top O 5 1k0
R3313 Resistor 5% 63mW Top O 5 1k0
R3314 Resistor 5% 63mW Top M 2 47R
R6010 Resistor 5% 63mW Bottom L 2 330R
R6011 Resistor 5% 63mW Bottom M 2 27k
R6013 Resistor 5% 63mW Bottom N 2 1k2
R6014 Resistor 5% 63mW Bottom N 2 2k2
R6015 Chipres 0W06 jumper 0402 Bottom N 2 0R
R6030 Resistor 5% 63mW Bottom P 4 10k
R6031 Resistor 5% 63mW Bottom O 2 10k
R6032 CHIPRES 0W06 2R2 J 0402 Bottom O 4 2R2
R6034 Resistor 5% 63mW Bottom P 2 10k
R6040 Resistor 5% 63mW Bottom O 2 100k
R6156 Chipres 0W06 jumper 0402 Bottom O 5 0R
R6159 Resistor 5% 63mW Bottom P 6 10k
R6160 Resistor 5% 63mW Bottom P 6 100k
R6161 Chipres 0W06 jumper 0402 Bottom O 4 0R
R7000 CHIPRES JUMPER 0603 Bottom C 8 0R
R7501 Resistor 5% 63mW Top H 3 2k2
R7502 CHIPRES 0W06 10K F 0402 Top G 4 10k
R7503 Resistor 5% 63mW Top I 4 4k7
RM-70
Nokia Customer Care Parts and layouts
Page 2 –20 COMPANY CONFIDENTIAL Issue 1
Copyright © 2005 Nokia. All rights reserved.
