Item Name PWB side X Y Value
R2104 CHIP VARISTOR VWM14V VC50V 0402 Bottom K 6 14V/50V
R2105 CHIP VARISTOR VWM14V VC50V 0402 Bottom J 6 14V/50V
R2106 CHIP VARISTOR VWM14V VC50V 0402 Top G 6 14V/50V
R2107 CHIP VARISTOR VWM14V VC50V 0402 Top G 5 14V/50V
R2114 CHIP VARISTOR VWM14V VC50V 0402 Top G 8 14V/50V
R2115 CHIP VARISTOR VWM14V VC50V 0402 Top G 9 14V/50V
R2200 Resistor 5% 63mW Top N 9 100k
R2201 Resistor 5% 63mW Top N 8 120k
R2202 Resistor 5% 63mW Top M 6 1k0
R2203 Resistor 5% 63mW Top N 6 1k0
R2204 Resistor 5% 63mW Top N 6 1k0
R2205 Resistor 5% 63mW Top N 6 1k0
R2206 Chipres 0W06 jumper 0402 Top N 6 0R
R2207 Chipres 0W06 jumper 0402 Top N 6 0R
R2208 Chipres 0W06 jumper 0402 Top N 6 0R
R2209 Chipres 0W06 jumper 0402 Top N 6 0R
R2212 Resistor 5% 63mW Top M 6 470R
R2213 Resistor 5% 63mW Top N 8 4k7
R2214 Resistor 5% 63mW Top N 8 4k7
R2216 CHIPRES 0W06 2M2 J 0402 Top N 8 2M2
R2307 Resistor 5% 63mW Top H 8 100R
R2401 Resistor 5% 63mW Top O 5 100k
R2404 CHIP VARISTOR VWM14V VC50V 0402 Bottom J 9 14V/50V
R2405 ASIP SIM INTERFACE **LOW CAP**BGA8 Bottom K 2 ~
R2406 Resistor 5% 63mW Bottom J 9 27k
R2407 Resistor 5% 63mW Top P 9 220R
R2408 Resistor 5% 63mW Top P 9 10k
R2409 ASIP SIM INTERFACE **LOW CAP**BGA8 Bottom N 9 ~
R2410 Chipres 0W06 jumper 0402 Bottom J 8 0R
R2411 Resistor 5% 63mW Bottom J 3 33R
R2412 Resistor 5% 63mW Bottom J 3 33R
R2413 RES NETWORK 0W03 4X33R J 0804 Bottom J 3 4x33R
R2414 RES NETWORK 0W03 4X100R J 0804 Bottom J 4 4x100R
R2415 RES NETWORK 0W03 4X100R J 0804 Bottom K 4 4x100R
R2417 NTC RES 47K J B=4050+-3% 0402 Top P 6 47k
