Nokia RM-70 User Manual

Item Name PWB side X Y Value
L7502 FERRITE BEAD 0.6R 600R/100MHZ 0402 Top I 4 600R/
100MHz
L7503 CHIP COIL 27N J Q27/800M 0402 Top I 7 27nH
L7504 CHIP COIL 22N J Q28/800M 0402 Top H 5 22nH
L7505 CHIP COIL 22N J Q28/800M 0402 Top H 5 22nH
L7515 CHIP COIL 15N J Q30/800M 0402 Top G 3 15nH
L7560 CHIP COIL 15N J Q30/800M 0402 Top H 3 15nH
M2100 SMD VIBRA MOTOR 1.3V 90MA 9000RPM Bottom F 7 ~
N2000 TI ANALOG SWITCH TS5A3159DCKR Top O 8 ~
N2001 TI ANALOG SWITCH TS5A3159DCKR Top P 8 ~
N2101 AF AMP TPA2012D2 77DB/217HZ CSP Bottom M 9 ~
N2300 TAHVO V5.2 LF TFBGA84 Top K 7 ~
N2301 WHITE LED DRIVER 4LEDS 500MW 8BUMP USMD8 Top K 9 ~
N3300 DC/DC CONV LM3671TLX-1.82V USMD5 Bottom I 4 ~
N6030 BC4-ROM1.0RDL Bottom O 3 ~
N6156 FM RECEIVER TEA5761UK N4B CSP (TI) Bottom O 5 ~
N7505 AHNE301A TRANCEIVER RFIC TFBGA144 Top H 4 ~
N7520 PA RF9282E6.3 GSM/EDGE 850/900/1800/1900 Top H 7 ~
R2000 Resistor 5% 63mW Top P 5 220R
R2001 ASIP MIC W/ESD RES+CAP+ZDI BGA11 Top P 6 ~
R2002 Resistor 5% 63mW Top P 7 10R
R2003 Resistor 5% 63mW Top P 7 10R
R2004 Resistor 5% 63mW Top P 7 10R
R2005 Resistor 5% 63mW Top P 7 10R
R2006 ASIP 4XESD **PB-FREE** BGA5 Bottom P 7 ~
R2007 ASIP SILIC USB OTG / ESD BGA11 Bottom Q 6 ~
R2008 Resistor 5% 63mW Bottom P 6 220k
R2009 Resistor 5% 63mW Top P 6 10k
R2010 Resistor 5% 63mW Bottom P 5 100R
R2017 Resistor 5% 63mW Bottom O 8 120k
R2070 CHIP VARISTOR VWM14V VC50V 0402 Bottom H 6 14V/50V
R2100 ASIP SINGLE ENDED MICROPHONE INTERF BGA8 Top P 7 ~
R2101 Resistor 5% 63mW Top Q 8 220R
R2102 Chipres 0W06 jumper 0402 Top O 7 0R
R2103 Chipres 0W06 jumper 0402 Top O 7 0R
RM-70
Nokia Customer Care Parts and layouts
Page 2 –18 COMPANY CONFIDENTIAL Issue 1
Copyright © 2005 Nokia. All rights reserved.
