Nokia RM-70 User Manual

Item Name PWB side X Y Value
L2272 FERR.BEAD 220R/100M 2A 0R05 0603 Top L 7 220R/
100MHz
L2273 FERR.BEAD 220R/100M 2A 0R05 0603 Top L 6 220R/
100MHz
L2301 FERR.BEAD 220R/100M 2A 0R05 0603 Top J 6 220R/
100MHz
L2302 INDUCT WW 10UH 0A65 0R35 4X4X1.2 Top K 6 10uH
L2304 CHOKE 22U M 0R7 0.35A 3.0x3.0x1.5 Top J 8 22uH
L2305 FERRITE BEAD 0R5 600R/100MHZ 0603 Top J 8 600R/
100MHz
L2306 FERRITE BEAD 0R5 600R/100MHZ 0603 Top I 8 600R/
100MHz
L2400 FERRITE BEAD 0.6R 600R/100MHZ 0402 Bottom H 6 600R/
100MHz
L2401 FERRITE BEAD 0.6R 600R/100MHZ 0402 Bottom H 6 600R/
100MHz
L2402 FERR.BEAD 240R7100M 0.4A 0R4 0402 Top Q 4 240R/
100MHz
L2403 FERR.BEAD 240R7100M 0.4A 0R4 0402 Top Q 5 240R/
100MHz
L2404 FERR.BEAD 240R7100M 0.4A 0R4 0402 Top O 5 240R/
100MHz
L3301 FERRITE BEAD 0.6R 600R/100MHZ 0402 Bottom H 4 600R/
100MHz
L3303 INDUCT WW 2.2UH 1A2 310 CASE SIZE Bottom I 3 2u2H
L6030 CHIP COIL 2N7+-0N3 Q29/800M 0402 Bottom O 3 2n7H
L6031 CHIP COIL 2N7+-0N3 Q29/800M 0402 Bottom O 3 2n7H
L6032 CHIP COIL 22N J Q28/800M 0402 Bottom O 3 22nH
L6156 CHIP COIL 47N G Q38/200MHZ 0603 Bottom O 5 47nH
L6176 CHIP COIL 120N J Q32/150MHZ 0603 Bottom P 4 120nH
L7000 FERRITE BEAD 0.6R 600R/100MHZ 0402 Bottom C 8 600R/
100MHz
L7001 FERRITE BEAD 0.6R 600R/100MHZ 0402 Bottom C 8 600R/
100MHz
L7010 FERR.BEAD 240R7100M 0.4A 0R4 0402 Bottom I 5 240R/
100MHz
L7011 FERR.BEAD 240R7100M 0.4A 0R4 0402 Bottom I 5 240R/
100MHz
L7500 CHIP COIL 12N J Q31/800M 0402 Top H 5 12nH
L7501 CHIP COIL 12N J Q31/800M 0402 Top H 5 12nH
RM-70
Parts and layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –17
Copyright © 2005 Nokia. All rights reserved.
