Nokia RM-70 User Manual

Item Name PWB side X Y Value
L2000 FERR.BEAD 220R/100M 2A 0R05 0603 Bottom P 3 220R/
100MHz
L2001 CHIP BEAD ARRAY 2X1000R 0405 Bottom Q 6 2x1000R/
100MHz
L2002 CHIP BEAD ARRAY 2X1000R 0405 Bottom Q 7 2x1000R/
100MHz
L2003 CHIP BEAD ARRAY 2X1000R 0405 Bottom Q 7 2x1000R/
100MHz
L2004 CHIP COIL 68NH J Q12/100MHZ 0603 Top Q 6 68nH
L2100 CHIP BEAD ARRAY 2X1000R 0405 Bottom K 6 2x1000R/
100MHz
L2102 CHIP COIL 56N J Q38/200MHZ 0603 Top F 6 56nH
L2103 CHIP COIL 56N J Q38/200MHZ 0603 Top F 5 56nH
L2104 FERR.BEAD 220R/100M 2A 0R05 0603 Bottom K 9 220R/
100MHz
L2105 FERR.BEAD 220R/100M 2A 0R05 0603 Bottom K 9 220R/
100MHz
L2106 FERR.BEAD 220R/100M 2A 0R05 0603 Bottom L 9 220R/
100MHz
L2107 FERR.BEAD 220R/100M 2A 0R05 0603 Bottom L 8 220R/
100MHz
L2108 CHIP COIL 56N J Q38/200MHZ 0603 Top G 8 56nH
L2109 CHIP COIL 56N J Q38/200MHZ 0603 Top G 9 56nH
L2111 FERRITE BEAD 0.6R 600R/100MHZ 0402 Bottom L 9 600R/
100MHz
L2112 FERRITE BEAD 0.6R 600R/100MHZ 0402 Bottom G 6 600R/
100MHz
L2113 FERRITE BEAD 0.6R 600R/100MHZ 0402 Bottom G 6 600R/
100MHz
L2202 FERR.BEAD 220R/100M 2A 0R05 0603 Top M 9 220R/
100MHz
L2203 FERRITE BEAD 0.6R 600R/100MHZ 0402 Top M 9 600R/
100MHz
L2204 FERRITE BEAD 0.6R 600R/100MHZ 0402 Top N 8 600R/
100MHz
L2205 FERR.BEAD 220R/100M 2A 0R05 0603 Top N 9 220R/
100MHz
L2206 FERRITE BEAD 0.6R 600R/100MHZ 0402 Top M 8 600R/
100MHz
RM-70
Nokia Customer Care Parts and layouts
Page 2 –16 COMPANY CONFIDENTIAL Issue 1
Copyright © 2005 Nokia. All rights reserved.
