Item Values
(EGSM900/GSM1800/GSM1900) 8-PSK 27/26/26 dBm
Table 20 Receiver characteristics
Item Values
Type Direct conversion, Linear, FDMA/TDMA
LO frequencies EGSM900: 3700...3840 MHz (4 x RX freq)
GSM1800: 3610...3760 MHz (2 x RX freq)
GSM1900: 3860...3980 MHz (2 x RX freq)
Typical 3 dB bandwidth +/- 91 kHz
Sensitivity min. - 102 dBm (normal condition)
Total typical receiver voltage gain (from
antenna to RX ADC)
86 dB
Receiver output level (RF level -95 dBm) 230 mVpp, single-ended I/Q signals to RX ADCs
RM-70
Nokia Customer Care System module
Page 8 –24 COMPANY CONFIDENTIAL Issue 1
Copyright © 2005 Nokia. All rights reserved.
