4.6.3.7 Setting the integral time for the internal PI controller
Note: This setting is available only if the internal PI controller is activated.
Select “Integr.-Time” in the control settings menu, then press the <Set> key.
In the upcoming modication dialogue set the integral time in minutes for the internal PI controller.
Factory setting: 8 minutes
Options: 1...60 minutes
4.6.3.8 Activating/Deactivating the supply air limitation
Note: This setting is available only if the control type is set to “External”, “Int. (P)” or “Int. (PI)”.
Select “Lim. Control” in the control settings menu, then press the <Set> key.
In the upcoming modication dialogue select the desired supply air limitation signal.
Factory setting: 0–10V
Options: 0–5V, 1–5V, 0–10V, 2–10V, 0–16V, 3.2–16V, 0–20mA, 4–20mA
In the upcoming modication dialogue activate or deactivate the supply air limitation (Signal Z).
Factory setting: Off
Options: On, Off
4.6.3.9 Selecting the supply air limitation signal
Note: This setting is available only if the external controller or the internal P or PI controller and the
supply air limitation are activated.
Select “Limitsignal” in the control settings menu, then press the <Set> key.
