33
The error messages generated by the last 20 malfunctions that occurred are saved in the malfunction
list of the Nordmann RC4/DC4 and can be interrogated.
Select the error history list:
Path: Main menu > Diagnostic > ErrorHistory
The last error that occurred is shown with:
– running number of the error
– date and time of occurrence
– error code (Warning: W..., Error: E...)
– error message
– additional info text regarding the error
Press < > and < > keys, in order to select further error messages in the list.
Press the <Esc> key several times to quit the error history list and to return to the standard operat-
ing display.
4.6.10.5 Setting the brightness of the backlight
Select “Brightness” in the display/LED settings submenu, then press the <Set> key.
In the upcoming modication dialogue set the desired brightness value for the backlight in % of the
maximum value.
Factory setting: 80 %
Setting range: 20...100 %
Display/LED
Steam-LED :Time-O
O-Timeout :5min
Contrast :30
Backlight :On
Brightness :80%
Esc Set
Brightness
80 %
80 %
Esc Set
Settings
Water Manag.:Set
Date :31-10-11
Time :12:00
GFCI-Mode :On
Display/LED :Set
Esc Set
ErrorHistory
E32 HumSensor broken
No sensor signal
humidity sensor def.
01/05 15-10-11 12:34
Esc Set
ErrorHistory
E33 Lim Sens broken
No sensor signal
humidity sensor def.
05/05 30-10-11 16:30
Esc Set
Menu
RC4 230V2
Standby
2011-10-31 12.00.00
Main Menu
Engineering :Set
Diagnostic :Set
User :Set
Esc Set
Diagnostic
Unit Status :Set
Remote Test :Set
Modul Test :Set
ErrorHistory:Set
Esc Set
4.7 Diagnostic functions
4.7.1 Interrogation of the malfunction list
