With the parameters in the “Power Limit” submenu you determine whether the Nordmann RC4/DC4
is to be operated with a x capacity limit (factory setting) or whether it is to be operated with a timer
controlled capacity limitation.
Note: set the desired capacity limitation in % of the maximum capacity of the humidier.
– Operation with x capacity limit:
Select “Power Limit” in the settings menu, then press the <Set> key.
4.6.3.10 Setting the lower limit value for the supply air limitation
Note: This setting is available only if the external controller or the internal P or PI controller and the
supply air limitation are activated.
Select “Limit Min” in the control settings menu, then press the <Set> key.
In the upcoming modication dialogue set the lower limit value in %rh for the supply air limitation.
Factory setting: 70 %rh
Options: 15 ... 95 %rh
4.6.3.11 Setting the upper limit value for the supply air limitation
Note: This setting is available only if the external controller or the internal P or PI controller and the
supply air limitation are activated.
Select “Limit Max” in the control settings menu, then press the <Set> key.
In the upcoming modication dialogue set the upper limit value in %rh for the supply air limitation.
Factory setting: 90 %rh
Options: 15 ... 95 %rh
4.6.4 Conguring the capacity limitation
Let the timer deactivated (Off) or deactivate the timer if necessary. Select “Power Limit”, then
press the <Set> key. In the upcoming modication dialogue set the value for the x capacity
limitation (Factory setting: 100 %, Setting range: 4kg/h unit: 30-100 %, 2kg/h unit: 50-100 %).
Controls
