0−1000 PSI Pressure Transducer and Amplifier
2
Part 1602989-02
E 2021 Nordson Corporation
Specifications
Range: 0−1000 psi (0−68.9 bar)
Nonlinearity: 1.0% F.S.
Hysteresis: 1.0% F.S.
Temperature Compensation of Pressure Transducer:
60−160 _F
(15−71 _C)
Temperature Effect:
S Zero
S Span
0 .01% F.S./ _F
0.02% RDG./ _F
Material 17-4 stainless steel
Amplifier Operating Voltage: 14−28 Vdc
Amplifier Operating Temperature:
-20−180 _F
(-20−82 _C)
Output Voltage: 1−4 Vdc (2.5 mA max) @ 1000 psi with 2.5 Vdc
Common Mode Offset
Calibration
The transducer amplifier has adjustment potentiometers for calibration purposes.
The assembly is calibrated at the factory and shipped with a calibration certificate.
Like all transducer
s, it should be calibrated periodically, usually once a year if ISO
processes are involved.
Calibration of the transducer is recommended annually to insure accurate and
reliable operation. Calibration should be performed with precision equipment
which has been calibrated to standards traceable to NIST (National Institute of
Standards and Technology). Contact your Nordson Container Specialist for more
information on calibration services.
See the table below for warnings and symbols in this instruction sheet.
Symbol Description
WARNING: Follow all safety instructions in the manual for
safe use
Do not disconnect under load. Turn o all power to the
module before connecting or disconnecting any cables
form the pressure transducer ampier to avoid equipment
damage.
