Leaf User Manual
P/N: 97-4000, Revision 08, Release date: 2020-11-10 Page 11 of 85
A
Emergency Off Switch
B
Micro USB Connection
C
Door Interlock / Warning Light Connection
NOTE
If using an external door interlock, a qualified electrical professional must install the
external switch, and the total length of the cable should not exceed 5 m (16 ft).
Bottom Panel Functions
A
B
C
