Error Messages
Error States
If error occurs regularly, contact Norlase technical support or your authorized Distributor.
Critical Error implies a safety issue that requires the system to immediately go to a
safe state.
Clearable Error indicates a problem with the system that requires that the system be
put into a safe state until the error is acknowledged by the user or returns within
specification.
Warning indicates a problem with the system that does not represent a serious
safety issue and does not require any system functions to be interrupted but does
require that the user be notified.
Code
Message
Critical
Clearable
Warning
Description
Action
1-1
Low Supply Voltage
X
Power Supply
Voltage is too low
Turn Key OFF, then ON
Call service if error persists.
1-2
Memory Problem
X
Internal Memory
Error
Turn Key OFF, then ON
Call service if error persists.
1-3
Clock Failure
X
Footswitch has
malfunctioned or
been disconnected
Turn Key OFF, then ON
Call service if error persists.
1-4
Board Temperature
out of range
X
Internal Temperature
is outside operating
specifications
Let temperature stabilize
until error clears.
Call service if error persists.
1-10
Laser Temp Range
X
Laser Temperature is
outside operating
specifications
Let temperature stabilize
until error clears.
Call service if error persists.
1-11
Laser Over Current
X
Laser/aiming beam
over current
detected
Turn Key OFF, then ON
Call service if error persists.
1-12
Laser Power
Monitor Failure
X
Power detectors not
responding
Turn Key OFF, then ON
Call service if error persists.
1-13
Laser Power Out of
Range
X
Power detectors
reading outside
calibrated range
Turn Key OFF, then ON
Call service if error persists.
1-20
Spot Size Zero
X
Spot Size mechanism
not returning to
default state
Turn Key OFF, then ON
Call service if error persists.
1-21
Spot Size Stuck
X
Spot Size mechanism
not responding to
commands
Turn Key OFF, then ON
Call service if error persists.
1-30
Footswitch not
detected
X
Footswitch not
responding
Check foot switch connection
and cable for damage.
Call service if error persists.
1-40
Interlock Reset
Timeout
X
Interlock not reset in
time
Check interlock Connection
Turn Key OFF, then ON
Call service if error persists.
1-41
Interlock Power Low
X
Interlock voltage too
low or not present
Check interlock Connection
Turn Key OFF, then ON
Call service if error persists.
