Page 232 of 488 Configuring a Small System Controller
553-3041-210 Standard 4.00 September 2007
2 Using one of the NTDU0606 CAT5 Ethernet cables:
a. Attach port number label “1” to the cable.
b. Install the cable firmly into the RJ-45 port on the 100BaseT
daughterboard (single port). Make sure that the cable end is inserted
completely. See Figure 84 on page 233.
Note: Do not connect the LED cable to the 100BaseT daughterboard
(single port).
