Installing system grounds Page 93 of 488
Communication Server 1000E Installation and Configuration
Follow Procedure 6 to install a ground bar.
Procedure 6
Installing an NTBK80 Ground Bar
1 Place the ground bar near the equipment.
Note: The ground bar is a bridging point for ground wires from up to
six components.
2 Connect the ground bar to the ground bus in the AC electrical panel using
#6 AWG wire. See Table 12 on page 93 for region-specific grounding
requirements.
3 Place a tag marked DO NOT DISCONNECT on the ground wire at the
electrical panel.
4 Test the ground
Refer to Figure 26 on page 94 for the NTBK80 Ground Bar
WARNING
A qualified technician or electrician must make the
connection in the AC electrical panel.
Table 12
Region-specific grounding wire requirements
Region Grounding wire requirements
Germany #8AWG (8.36mm
2
) green/yellow
wire
Other regions in Europe not smaller than #6 AWG
(13.3 mm
2
) at any point
UK two green/yellow wires no thinner
than two 10 mm
2
