System components Page 65 of 488
Communication Server 1000E Installation and Configuration
• rack mounted to a 19-inch rack
• provide configurable username for each port
19-inch rack
All CS 1000E system components are mounted in a customer-supplied
19-inch rack. Ground the rack and equipment to the NTDU6201 Ground Bar.
System cables
Table 9 on page 67 lists the cables required with the CS 1000E system.
Table 8
MRV IR-8020M Terminal Server profile
Property Description
Product Code NTVW00AB
Height • 1 U (1 U = 1 3/4 inch or 4.4 cm)
Power • Power cord connector is located on the left-hand
corner on the unit’s backplane.
• Power supplies are factory installed and not
customer replaceable.
• Unit is AC powered (120 V AV @ 1.58 amps).
Cooling • Forced air cooling with side-to-side air flow.
• The fans run at a single speed.
• Ensure that equipment ventilation openings are
not blocked.
Card slots • None
Connectors • Twenty console ports for modular RJ-45
connectors
• One RJ-45 (10BaseT) network interface
