Table 41 shows the slot assignments for the MG 1000T Media Gateway and
Media Gateway Expansion
Procedure 80
Installing a Voice Gateway Media Card in a card slot
The ELAN subnet and TLAN subnet should already be connected on the back
of the Media Gateway. If not, refer back to “Connecting CS 1000E system
components” on page 103.
Table 41
MG 1000T Media Gateway/Expansion card slot assignments
Media Gateway/Media Gateway Expansion
Media Gateway
0
Media Gateway
1
Media Gateway
2
Media Gateway
3
Media Gateway
4
Physical
card slot
Logical
card slot
Physical
card slot
Logical
card slot
Physical
card slot
Logical
card slot
Physical
card slot
Logical
card slot
Physical
card slot
Logical
card slot
Media
Gateway
1 1 1 11 1 21 1 31 1 41
2 2 2 12 2 22 2 32 2 42
3 3 3 13 3 23 3 33 3 43
4 4 4 14 4 24 4 34 4 44
5 * 5
*
5
*
5
*
5
*
6 * 6 * 6 * 6 * 6 *
Media
Gateway
Expansion
7 7 7 17 7 27 7 37 7 47
8 8 8 18 8 28 8 38 8 48
9 9 9 19 9 29 9 39 9 49
10 10 10 20 10 30 10 40 10 50
Note: The bottom most card slot in the Media Gateway is reserved for the SSC card.
