Nortel VPN Client - Table 3 Supported Usetokens and Tokentype Settings

Chapter 2 Customizing the client 31
Configuring the Contivity VPN Client
As long as the file resides in the installation directory (where setup.exe is located),
the installation procedure copies the file to the appropriate directory and
overwrites the existing baynet.tbk file.
Each connection profile is defined between square brackets [ ], for example
[MyVPNConnection]. The following entries represent the baynet.tbk file that
resides in each Profile section:
• Description—user interface description field.
• Dialup—dial-up profile. The value (None) indicates there is no dial-up
profile.
• Username—user interface user name, or when using Entrust* authentication
this is the user’s .epf file.
• TokenType—used in combination with UseTokens to indicate the type of
authentication being used.
The following combined settings are supported (Table 3):
• UsePAPGroup—0 indicates no RADIUS authentication; 1 indicates RADIUS
authentication.
• GroupName—Options > Authentication Options dialog box Group Name
field.
• SavePassword—0 indicates that the user did not save the PIN/Password; 1
indicates that the user saved the PIN/Password.
Table 3 Supported UseTokens and TokenType settings
UseTokens TokenType
0 0. Username/password authentication type
1 1. AXENT* hardware token
1 2. Security Dynamics hardware token
0 3. RADIUS authentication
1 4. AXENT software token
1 5. Security Dynamics SoftID software token
0 6. Entrust certificate
0 7. (Reserved)
0 8. Microsoft CAPI stored Certificate
