Chapter 2 Customizing the client 45
Configuring the Contivity VPN Client
Figure 14 is a task bar icon that indicates that the client is receiving data into the
tunnel.
Figure 14 Blink left (blinkleft.ico)
Figure 15 is a task bar icon that indicates that data is being both transmitted and
received through the tunnel.
Figure 15 Both (blinkboth.ico)
Figure 16 is an icon group that shows activity during the client connection
process. Activity is shown through a cycle of four different icons with an arrow
pointing clockwise through each of the four quadrants of the circular icon.
Figure 16 Client connecting icons
To replace the client connection icons, create a series of icons and rename them
(connect1.ico, connect2.ico, connect3.ico, connect4.ico), then copy them into
your custom installation directory with all of the custom installation files.
Custom bitmaps
This section describes how to insert custom bitmaps in the main client dialog box
message, the client status message, and the Extranet Connection Manager dialog
box.
Client dialog bitmap (eacdlg.bmp)
Figure 17 on page 46 is the bitmap on the main dialog box of the client.
