39
Document 15949 Rev. E 4/12/95 P/N 15949:E
Table 4-1: Auto-Programming the AIM-200
Programmer System 5000
1. Insert the PK-1 Programming
Key.
CPU-5000 will register a System
Trouble condition.
Red alarm LEDs on Zones 1, 2, and 3
and the DISPLAY STATUS and ENTER
LEDs will flash at the faster rate.
EP
will be displayed for “Enter
Password.”
2. Acknowledge the System
Trouble (if desired).
The CPU-5000 piezo sounder will
silence.
3. Enter the Auto-Program
password: 231-1332.
The LEDs illuminated on the AIM-200
will flash at the slower rate.
Push ENTER. All LEDs will be turned off
AP
will be flashing for
“Auto-Program.”
The AIM-200 polls all 198 possible
device addresses. It stores the address
and type of each device found installed
on the loop (this process could take
several seconds). It then compares
each device against the old information
stored in its memory.
If a mismatch is found between the
devices installed on the loop and the
information in memory, information
about the new device is displayed.
4. The device information can be
changed by the AIM-200
programmer.
See 4.1 The Programming Display.
5. You may accept the new device
by pressing ENTER, or reject
the device and retain the
information that was in memory
by pressing SKIP.
The AIM-200 proceeds to the next
mismatch, and repeats the process.
After all mismatches are accepted or
rejected, the AIM-200 displays a count
of the number of programmed detectors,
alternating with a count of programmed
modules.
6. You may advance to Program
Edit mode by pressing ENTER;
return to Auto-Program mode by
pressing SKIP, or resume
normal operation by removing
the PK-1 key.
