44
Document 15949 Rev. E 4/12/95 P/N 15949:E
4.7 Display Status
When the operator wishes to view the status and program for a device, the Display Status/
Sensitivity function is used. This function is entered directly by inserting the PK-1 Program-
ming Key and pressing the DISPLAY STATUS switch. No password is required.
Note: The AIM-200 will cease monitoring its devices while in this mode and the CPU-5000
will report System Trouble.
Alternately, this mode may be entered without key or password by pressing and holding the
DISPLAY STATUS switch in for two seconds. Continue to hold the DISPLAY STATUS switch
in with one hand while performing the Step function with the other hand.
Displaying the Status of Intelligent Detectors
When the Display Status mode is entered, the digital display will repeatedly flash the ad-
dress, type and sensitivity of the detector assigned to the lowest address. The user can
scroll through all detectors using the STEP-FORWARD and STEP-REVERSE switches. The
SKIP switch advances addresses rapidly.
Detector Device Type/Status
The Device Type/Status field displays two characters for intelligent detectors, outlined be-
low.
Left Digit Right Digit
P =Photo Detector Blank = Normal sensitivity
I = Ion Detector L = Low Sensitivity
H = Heat Detector H = High Sensitivity
A = Alarm
F = Fault (maintenance Alert)
d = Disabled
E = Error--No response from a device (the AIM-200 is
programmed for a device that is in trouble or not
physically installed on the loop).
U = Unsatisfactory (Failed automatic detector test)
Alarm Threshold Percentage
The percent of alarm threshold for detectors is displayed with a decimal point as illustrated
below.
.43
43% of Alarm Threshold
1.2
120% of Alarm Threshold
