4.6 Default Zone Map
Upon initial power up, and after clearing AIM-200 memory (Program Clear), intelligent de-
tectors and addressable modules installed on an AIM-200 loop are automatically mapped to
default zones. Any changes to this map must be made through Program Edit. This default
map is illustrated in Figure 4-1.
Figure 4-1: Default Zone Map
