Notifier AIM-200 User Manual

49
Document 15949 Rev. E 4/12/95 P/N 15949:E
Table 5-1: AIM-200 Event Codes
Device Type Status
P
Photo Detector Normal, med. sensitivity
PL
Photo Detector Normal, low sensitivity
PH
Photo Detector Normal, high sensitivity
PA
Photo Detector Alarm
PF
Photo Detector Trouble
PE
Photo Detector No answer
Pd
Photo Detector Disabled
PU
Photo Detector Unsatisfactory (failed automatic self-test)
I
Ion Detector Normal, med. sensitivity
IL
Ion Detector Normal, low sensitivity
IH
Ion Detector Normal, high sensitivity
IA
Ion Detector Alarm
IF
Ion Detector Trouble
IE
Ion Detector No answer
Id
Ion Detector Disabled
IU
Ion Detector Unsatisfactory (failed automatic self-test)
H
Heat Detector Normal
HA
Heat Detector Alarm
HF
Heat Detector Trouble
HE
Heat Detector No answer
Hd
Heat Detector Disabled
HU
Heat Detector Unsatisfactory (failed automatic self-test)
G
Monitor Module Normal
GA
Monitor Module Alarm
GF
Monitor Module Trouble
GE
Monitor Module No answer
Gd
Monitor Module Disabled
C
Control Module (NAC) Normal
CA
Control Module (NAC) Alarm output
CF
Control Module (NAC) Trouble
CE
Control Module (NAC) No answer
Cd
Control Module (NAC) Disabled
CO
Control Module (Relay) Open (OFF)
CC
Control Module (Relay) Closed (ON)
CF
Control Module (Relay) Trouble
Cd
Control Module (Relay) Disabled
LF
Line Fault (Style 6)
SF
CPU loss of communication
EP
Enter Password
AP
Auto Program
Note: Invalid device type = E (left digit) Maintenance Alert = F (left digit)
