8
Document 15949 Rev. E 4/12/95 P/N 15949:E
BGX-101L
The addressable manual pull station features a key-lock reset. The pull
station responds to an address set by the installer with built-in rotary
decimal switches. Includes key.
System Sensor (SSD) A2143-00
The 47K end-of-line resistor assembly is used in the supervision of MMX-1 Monitor and
CMX-2 Control Module circuits. It is included with each MMX-1 or CMX-2 module.
N-ELR
The N-ELR resistor assortment is required for use in Canada. It provides
a variety of resistor values to mount to a single ELR plate (included).
Resistors can be used for the supervision of an MMX-1 monitor module
or CMX-2 control module circuit.
Resistors included:
120 ohms, 470 ohms, 1.8K, 2.2K, 4.7K, 6.8K, 10K, 27K, and 47K.
PUSH IN
THEN
PULL DOWN
FIRE
