Appendix F FlexPak6 Technical Specifications
F.1 FlexPak6
INPUT/OUTPUT CONNECTORS
ANT
TNC female jack, 50  nominal impedance
+5 VDC (±5%)100 mA max (output from FlexPak6 to antenna/LNA)
PWR 4-pin LEMO
COM1 9-pin DB9 (maximum baud rate 921600)
COM2
9-pin DB9
a
(maximum baud rate 921600)
a. COM2 can be dynamically changed to RS-422 by grounding I/O pin 9. Refer to Table 47, FlexPak6 I/O Port Pin-Out
Descriptions on page 192 for details.
USB mini-AB
Ethernet, CAN, I/O DB-HD15
PHYSICAL
Size 45 x 147 x 123 mm
Weight 337 g maximum
Mounting System
Integral flange with two 7 mm (9/32 inch) diameter mounting holes 133 mm (5.25
inches) apart
ENVIRONMENTAL
Operating Temperature -40C to +75C
Storage Temperature -40C to +85C
Humidity MIL-STD-810G, Method 507.5, Procedure II (95%)
Immersion IEC 60529 IPX7
Random Vibration MIL-STD-810G, Method 514.6, Category 24 (20 to 2000 Hz, 7.7 g RMS)
Sinusoidal Vibration SAE J1211 (10 Hz to 1000 Hz, 4 g)
Bump IEC 60068-2-27 (10 g)
Shock MIL-STD-810G, Method 516.6, Procedure 1 (40 g)
Acceleration MIL-STD-810G, Method 513.6, Procedure II (4 g, 8 g, 12 g, 16 g)
POWER REQUIREMENTS
Input Voltage +6 to +36 VDC
Power Consumption
Typical 1.8 W (power consumption values for GPS L1/L2 at 6 VDC with Ethernet
disabled)
Maximum 3.1 W
In-Rush Current Consumption 6.6 A for less than 60 s (typical)
