Synthesis System Analogue Sound Modelling.
Polyphony 16 Voices.
Sound Sources per Voice 3 Oscillators, 2 Ring Modulators and a Noise Generator.
Modulation Matrix Comprehensive Modulation Matrix with 130 possible routings.
Multitimbral capacity 6 part Multitimbral.
Filter 12, 18 and 24 dB per octave Resonant filter configurable in Low Pass, High Pass and Band Pass modes.
The filter also features an overdrive control & 9 dual filter modes.
LFOs 2 LFOs capable of oscillating at Audio rates.
Program Effects Distortion, Comb Filter, EQ, Reverb, Chorus/Flanger/Phaser, Delay and Panning effects for each Program.
Total number of Effects 42 Effects available simultaneously. 7 Effects for each of the 6 Parts of a Performance.
Vocoder 40 Band Vocoder that can run simultaneously with the Full Synth Engine (no reduction of polyphony etc).
Number of Outputs 6 assignable polyphonic outputs with 128 x Oversampling Delta Sigma DACs for each output.
Number of Inputs 2 Audio Inputs. Signals can be routed through the Synth Engine (Filters), Effects or both. 20 bit ADCs.
Input Sensitivity Selectable between Microphone, Guitar, -10dB and +4dB Levels.
Metering PPM Metering with Variable Trim & 40 Band Spectrum Analyser on the Display.
Number of Programs 256 Programs in 2 banks.
Number of Performances 128 Performances.
Arpeggiator Built in Arpeggiator with 384 Preset Polyphonic, Preset Monophonic and User Programmable
Polyphonic and Monophonic Patterns. 6 Arpeggiators are available simultaneously in Performance mode.
Control All knobs, switches and Parameters transmit MIDI Controllers and NRPNs.
Operating System Flash upgradeable operating system via MIDI.
Power Requirement Multi Voltage external power supply.
MIDI In/Out/Thru.
Dimensions 6U Rackmount (Rack Kit Included) H63mm (including knobs) D193mm W383mm.
Weight 4kg.
Specification subject to change without prior notice due to improvements.
