G. Generator Housing, Installation and Mounting
G.9 Install NPS supplied six (6) Grade 8 steel bolts (See Exhibit 5) through the
Generator Installation Bracket then through pre-attached rubber isolation feet. See
Exhibit 4.
G.10 Use a torque wrench or torque stick for installation of the NPS supplied
installation Grade 8 steel bolts (6) 5/16-18 NC. Lengths for Grade 8 steel bolts are:
• for towable segment RVs, 31.75mm (1.25")
o
Torque should be 27.116 Nm (20 ft-lbs)
• for motorized segment RVs, 57.15mm (2.5")
o
Torque should be 27.116 Nm
(20 ft-lbs)
G.11 The electrical, fuel and exhaust connections to the Generator may be
made at any time, in any order, but all must be completed PRIOR to
connecting the negative (-) DC power on the battery.
Page 24 of 55 Rev. 1
