I. Electrical Connection
Remote Start Panel Connection
I.21 DANGER! ELECTRICAL ARC FLASH, SPARK and FIRE HAZARD
Prior to performing any work on the DC Power Connection, verify the black negative
(-) cable is disconnected and the battery is de-energized. Failure to disconnect
negative (-) cable may create an electrical arc flash, spark or fire and could result in
death or extreme bodily injury to the installer or operator.
I.22 DANGER! DC Power Connections must always follow a strict protocol of
disconnecting the black negative (-) battery cable first and then disconnecting the red
positive (+) battery cable. When reconnecting the DC Power Connection, the red
positive (+) battery cable must be connected first, and the black negative (-) battery
cable must always be connected last. Failure to follow this strict sequence will result
in an electrical arc flash and may result in death or extreme bodily injury to the
installer or operator.
I.23 When running wiring, be alert to any sharp edges or metal RV components,
which could damage or compromise wiring or its insulation, either upon initial
contact or as a result of vibration from normal operations. Damage to any part of the
wiring may create an electrical arc flash, fire or electrical shock and could result in
death or extreme bodily injury to the installer or operator.
I.24 When running wiring, be alert for any RV components or parts, which may be
hot and compromise the integrity of the wiring or its insulation. Damage to any part
of the wiring may create an electrical arc flash, fire or electrical shock and could
result in death or extreme bodily injury to the installer or operator.
I.25 DO NOT run the Remote Start Panel wires and the 120Volt leads next to each
other. Close proximity of the two wire sets may result in electrical signal interference to
the hard line Remote Start Panel inside the RV.
I.26 Locate the Remote Start Wiring Harness and the Remote Start Panel. See Exhibits
12, 13, 14.
I.27 Route the Remote Start Wiring Harness through the RV, between Generator
housing compartment and the install location for the Remote Start Panel, based on the
specifications for that particular RV model.
• The spade connector end of the Remote Start Wiring Harness terminates at the
Remote Start Panel.
• The black female connector end of the Remote Start Wiring Harness terminates at
the Generator.
• Some RV models may not use the Remote Start Panel or any/all of the Remote Start
Wiring Harness or connections, please refer to your RV model manufacturer
specifications for guidance or contact NPS at (866) 407-1727 or
www.npsrvpower.com.
