J. Fuel Connection
J.1 DANGER! GASOLINE and VAPORS are FLAMMABLE and EXPLOSIVE
• Keep multi-class ABC fire extinguishers within reach of installer and readily
available throughout the installation
• Do not smoke or permit others to smoke at or near install location
• All rags soiled with gasoline or oil must be discarded in a fire-proof container
• Routinely check for leaks and collections of gasoline pooling in install area
• Secure and shield fuel lines separately and away from electrical wiring to prevent
accidental ignition
• Keep all ignition sources away from fuel lines and including:
o
open flames
o
arc producing equipment
o
sparks
o
pilot lights
o
electrical switches
J.2 NPS Generators may only be used in towable applications (fifth-wheel and
bumper-pull) which are equipped with an ECI fuel system built specifically for
connecting to NPS Generators.
J.3 RV models equipped with a NPS ECI fuel system will be identified by a red tag.
See Exhibit 1.
• If this tag is not present or cannot be located on the fifth-wheel or bumper-pull, DO
NOT proceed with the installation of the Generator.
• This prohibition does not apply to motorized applications.
K.4 Locate the fuel line from the RV (refer to your Manufacturer for model specific
location)
J.5 Locate the Fuel Line and Purge Line spout off the right side of the Generator
(below the rubber grommet for the Remote Start Wiring Harness and along side the
12Volt negative (-) ground connection. See Exhibit 10.
J.6 Slide the end of the RV fuel line over the Generator Fuel Line spout. See Exhibit
10.
J.7 Secure tightly with the RV Manufacturer provided fuel line clamp.
J.8 Check connection for any leaks of fuel or vapors.
Page 44 of 55 Rev. 1
