NPS Y6000eco - Exhibit 14 - Wiring Harness - Connections at Generator

Exhibit 14 - Wiring Harness - Connections at Generator
Page 43 of 55 Rev. 1
Rubber
Grommet
for
Wiring
Harness
(outside
Generator)
Rubber
Grommet
with
Wiring
Harness
threaded (inside
Generator)
Generator
Service
Access
Door
(open)
Black female-end
Connector
to Remote Start
Panel Wiring Harness
(fully connected
to male-end Connector)
DC Power
12Volt
Circuit
Breaker
Black
male
-end
Connector
to
Generator
DC Power
12Volt
Master
Power Switch
Wiring
Harness to
Remote
Start
Panel
DC Power
12Volt Ground
Black female-end
Connector to
Remote
Start
Panel Wiring Harness
(fully connected
to male
-end Connector)
Black
male
-end
Connector
to
Generator
Warning
Label
