I. Electrical Connection
DC Power Connection (12Volt) - Generator to RV Battery Compartment
I.17 DANGER! ELECTRICAL ARC, SHOCK and FIRE HAZARD
Prior to performing any work on the DC Power Connection, verify the black
negative (-) cable is disconnected and the battery is de-energized. Failure to
disconnect negative (-) cable may create an electrical arc flash, spark or fire and
could result in death or extreme bodily injury to the installer or operator.
I.18 DC Power Connections must always follow a strict protocol of disconnecting
the black negative (-) battery cable first and then disconnecting the red positive (+)
battery cable. When reconnecting the DC Power Connection, the red positive (+)
battery cable must be connected first, and the black negative (-) battery cable must
always be connected last. Failure to follow this strict sequence will result in an
electrical arc flash and may result in death or extreme bodily injury to the installer
or operator.
I.19 Locate the battery compartment in the RV.
• Locate the red positive (+) battery terminal.
• Route or connect the red positive (+) battery cable to the red positive (+) terminal on
the Generator.
• Locate the black negative (-) battery terminal.
• Route or connect the black negative (-) battery cable to the black negative (-)
terminal on the Generator. If connecting complete only after entire installation is
completed.
II.20 Before starting Generator verify the RV battery(ies) are fully charged.
