NPS Y6000eco - Exhibit 13 - Wiring Harness Connectors

Exhibit 13 - Wiring Harness Connectors
Page 42 of 55 Rev. 1
Female-end
Connector
DC Power
(12Volt
red
Positive
(+)
Battery Connection)
Generator Service
Access Door
Warning
Label
Run Light
Hour Meter
(orange wire)
Battery
Ground
(b i)
Stop
(green
Start
(red
Start light
Battery
(blue wire)
Female-end
Connector
(wire
color
and
placement)
Warning
Label
DC Power
(12Volt red
Positive (+)
Battery
Connection)
Generator
Service
Access
Door (open)
Male-end
Connector
Start Light
Battery
(orange wire)
Battery
Ground
(b i)
Stop
(green
Start
(red
(blue
wire)
