Revision 1.03
Description 1-3
Thus the above model number be similar to:
20/70-CMTX7-L5/E1.5-CCC-YZ
CCC = Nucomm assigns a frequency plan number for each unique frequency channel
combination. Contact your Nucomm representative for further information.
YZ = Miscellaneous options as listed in the table below. The model number is formed by
appending as many letter codes as appropriate.
LETTER CODE
OPTION
AUDIO
A2
2 AUDIO
A4
4 AUDIO
B
AES ENCRYPTION
X
XLR AUDIO
MODULATION + VIDEO
C2
COFDM / FM
C4
COFDM / HD ENABLED
C8
COFDM / FM / HD ENABLED
C10
FM ONLY
C12
COFDM / FM / VSB / HD ENABLED
C15
COFDM / FM / VSB / HD READY
C17
COFDM / FM / HD READY
Options that are not a standard part of the system are indicated in this manual by
shaded text as shown here.
