Nucomm CHANNELMASTER TX7 - Figure 4-7: Channelmaster TX7 Rear Panel (All Models)

Revision 1.03
Installation 4-7
DCAC
ON
7
8
ITEM DESCRIPTION
11 RF Connector
12 Power Switch
Figure 4-7: ChannelMaster TX7 Rear Panel (All Models)
