Table 3-5: Frequency Plan (US),
12/13 GHz
12/13 GHz (25 MHz)
(Frequency Range 12,700 MHz -
13,250.0 MHz)
Channel Offset Receive Frequency MHz
1 -
12,706.25
1 0
12,712.50
1 +
12,718.75
1 ++
12,725.00
2 -
12,731.25
2 0
12,737.50
2 +
12,743.75
2 ++
12,750.00
3 -
12,756.25
3 0
12,762.50
3 +
12,768.75
3 ++
12,775.00
4 -
12,781.25
4 0
12,787.50
4 +
12,793.75
4 ++
12,800.00
5 -
12,806.25
5 0
12,812.50
5 +
12,818.75
5 ++
12,825.00
6 -
12,831.25
6 0
12,837.50
6 +
12,843.75
6 ++
12,850.00
7 -
12,856.25
7 0
12,862.50
7 +
12,868.75
7 ++
12,875.00
8 -
12,881.25
8 0
12,887.50
8 +
12,893.75
8 ++
12,900.00
9 -
12,906.25
9 0
12,912.50
9 +
12,918.75
9 ++
12,925.00
10 -
12,931.25
10 0
12,937.50
10 +
12,943.75
10 ++
12,950.00
12/13 GHz (25 MHz) (Con’t)
Channel Offset Receive Frequency MHz
11 -
12,956.25
11 0
12,962.50
11 +
12,968.75
11 ++
12,975.00
12 -
12,981.25
12 0
12,987.50
12 +
12,993.75
12 ++
13,000.00
13 -
13,006.25
13 0
13,012.50
13 +
13,018.75
13 ++
13,025.00
14 -
13,031.25
14 0
13,037.50
14 +
13,043.75
14 ++
13,050.00
15 -
13,056.25
15 0
13,062.50
15 +
13,068.75
15 ++
13,075.00
16 -
13,081.25
16 0
13,087.50
16 +
13,093.75
16 ++
13,100.00
17 -
13,106.25
17 0
13,112.50
17 +
13,118.75
17 ++
13,125.00
18 -
13,131.25
18 0
13,137.50
18 +
13,143.75
18 ++
13,150.00
19 -
13,156.25
19 0
13,162.50
19 +
13,168.75
19 ++
13,175.00
20 -
13,181.25
20 0
13,187.50
20 +
13,193.75
20 ++
13,200.00
21 -
13,206.25
21 0
13,212.50
21 +
13,218.75
21 ++
13,225.00
22 -
13,231.25
22 0
13,237.50
22 +
13,243.75
22 ++
13,250.00
