Revision 1.03
Specifications and Frequency Plans 3-1
3. SPECIFICATIONS AND FREQUENCY PLANS
RF Performance:
Tuning step size: ..................................... 250 kHz (US), 100 kHz (International)
70 MHz input:........................................... –10 dBm to 0 dBm (75 Ω)
Frequency stability: ................................. ± 5 ppm (.0005%)
Power Output
Standby mode: ................................... No RF output
Normal mode: .................................... Instant on frequency transmission
HI power = Full power (see Table 3-1)
LOW power = 6 dB drop (typical)
Table 3-1 lists band coverage, and maximum power levels for single band configurations.
NOTE: Dual and Tri-band configurations may not support the maximum power level.
Table 3-1: ChannelMaster TX7 Specifications
Base
Model
Frequency
(GHz)
Band
Designator
(AA*)
Power
Designator
(BB*)
Analog Power
(dBm)
Digital Power
(dBm)
L5 41 37
23CMTX7 1.9 - 2.5 23
L8 41 39
L5 41 37
25CMTX7 2.3 - 2.7 25
L8 41 39
nnCMTX7 2.7 - 6.4 Contact Nucomm for specific bands and power levels.
B1 33 30
70CMTX7 6.4 - 7.1 70
E1.5 37 32
B.5 33 27
75CMTX7 7.1 - 7.75 75
E1.5 37 32
B.5 33 27
82CMTX7 7.7 - 8.5 82
E1.5 37 32
nnCMTX7 8.5 -10.0 Contact Nucomm for specific bands and power levels.
110CMTX7 10.0 - 10.6 110 C.5 35 27
nnCMTX7 10.6 - 12.7 Contact Nucomm for specific bands and power levels.
130CMTX7 12.7 - 13.2 130 C.5 35 27
nnCMTX7 13.2 – 15.0 Contact Nucomm for specific bands and power levels.
* Refer to Section 1.2
