Nucomm CHANNELMASTER TX7 - Figure 4-6: Channelmaster TX7 Front Panel (XLR Version)

Revision 1.03
4-6 ChannelMaster TX7 Transmitter
1
2
4
5
7
8
9
10
ITEM DESCRIPTION
1 Power and RS232/485
2 ASI IN
4 70 MHz IN
5 VIDEO IN (For Composite, Baseband, or SDI Input)
7 AUDIO 1 Input
8 AUDIO 2 Input
9 Firewire (Note 1)
10 ASI OUT
Note 1: Check with Nucomm for Availability of This Feature
Figure 4-6: ChannelMaster TX7 Front Panel (XLR Version)
