ChannelMaster TX7
Main Menu
Composite
7
SDI
70MHz
ASI
1
COFDM
DVB-S
VSB
Power: On, Off
Constellation: QPSK, 16QAM, 64QAM
Code Rate: 1/2, 2/3, 3/4, 5/6, 7/8
Guard Interval: 1/4, 1/8, 1/16, 1/32
Bandwidth: 6MHz, 7MHz, 8MHz
Audio1: LINE/LINE, LINE/MIC, LINE/MIC+PP, AES/EBU,
Embedded
2
, Tone, Off
Bit Rate: 128K, 256K,384K
6
Level(L): 0dB (-6 to +6) (default: 0dB)
5
Level(R): 0dB (-6 to +6) (default: 0dB)
5
Input Type:
0: NTSC: 720x480(4:2:0)
8
The following require >10mbps
1: NTSC: 720x525(4:2:2)
The following require >19mbps
2: 1080/59.94i: MP@HL
3: 1080/59.94i: MP@H14L
4: 720/59.94p: MP@HL
5: PAL: 720x576(4:2:0)
8
6: PAL: 720x625(4:2:2)
7: 1080/50i: MP@HL
8: 1080/50i: MP@H14L
9: 720/50p: MP@HL
GOP: 0-5
Service Name: user text
Service Provider: user text
PCR PID: user selectable
Video PID: user selectable
Audio1 PID: user selectable
Audio2 PID: user selectable
Service Rate: Auto/Fixed
(bps)
Frequency Direct: YES, NO
Start in: YES, NO
Save Pre-Set: YES, NO
BAS Menu: YES, NO
Preset Lock RF CH: YES, NO
Video Present: STDBY, Bars
Mode: Remote/Local, Local Only
Interface: RS232, RS485
Address: (Hex) 0x01 – 0xFF
Baud Rate: 2400, 9600, 19200, 38400, 57600, 115200
CAUTION!
Allows the user to
Modify the Band Plan.
Serial Number
Model Number
Front Panel Rev
Config Data #
Frequency Plan #
ONLY FOR FACTORY
AUTHORIZED USE!
(Password Required)
2GHz Freq Plan: 2G(17),2G(12)
BW(2G(17)/7/13): 4MHz, 3MHz
BW(2G(12)8-10): 4MHz, 3MHz
Software Version
Monitor +48v
3
,
+12v & +5v levels
Temperature of
Control Unit,
and RF Head
3
Software Version
Software Date
Current Rate
Maximum Rate
Monitor
+10v, +5v
& Loop levels
Software Version
Monitor +48v,
+12v & +5v levels
Input: OFF, LINE/LINE, LINE/MIC, LINE/
MIC+PP, TONE, AES/EBU, Embedded
2
Insertion: (dB) (default: -28dB)
Gain: (dB) (default: 0dB)
Freq (2(17)/7/13): (MHz)
4
Freq (2(12) 1-7): (MHz)
4
Freq (2(12) 8-10): (MHz)
4
Inverse: Normal, Inverse
Emphasis: Emphasis, Flat
Filter: Bypass, 3.90 – 5.60
Deviation Bandwidth: (display only)
SC1
(L)
SC1
(R)
MENU
Underlining denotes a Factory
Default setting.
SC2
(L)
SC2
(R)
Certain menu items may not be
available on a given system due to
the many customizable features.
Type: 2VSB,
8VSB, 8TVSB
Bandwidth: 6MHz
Monitor Alarm
BASFactoryFrequencyRestore
VersionRemoteOptions
Restore
Factory Defaults?
YES, NO
System
Input Modulation
ServiceVideoAudio
Encoder
RF Head
3
UpconverterMod / EncTemperaturePSU
View Active
Alarms
VSBDVB/SCOFDM
VideoAudio
FM
Mode
Select
Parameter
Setup
1
Only available with Digital Modulation
2
Only available with SDI input
3
TX7T only
4
Factory defaults: 4.83, 6.2, 6.8, 7.5MHz
5
Only available with Analog Modulation
6:
Bit rate forced to 384k in GOP 0 mode.
7:
Disabled in HD mode.
8
:
The video bit rate will be limited to 15mpbs.
Audio2: (same as above if installed.)
Mux
(Not Used)
