Operator Panel Description
en-938821/2 3 - 7
3
3.1.3 Status Window
The status window shows the status of the CNC at any given time via indicators displayed in 17 fields.
When no indicators are required in a field, it is not displayed.
LOAD
MDI
.1
TLCOMP
/
M01 INCYC CN1
MSGFDHLD
OVER
N_POS
LCASE
NC ?? CYHLD
AXRCL
18234567
17 916 15 14 13 11 10
mm
12
1 - Current mode (See list of modes: 3.3.2.2)
2 - Entry of tool dimensions (TLCOMP), entry of tool wear offsets
(WEAR +) or cancellation of tool wear offsets (WEAR 0)
3 - Block skip (/) enabled
4 - Fault (NC ?? flashing) or MOS not performed (HOME flashing)
5 - Machining stop (CYHLD)
6 - Feed interruption (FDHLD)
7 - Message present (MSG)
8 - Overtype text mode (OVER) or insert mode (INSRT)
9 - Upper case letters (CAPS) or lower case letters (LCASE)
10 - Axis not in position (N_POS) or hardcopy in progress (HCOPY)
or hardcopy fault (HCDEF)
11 - Panel number (KBD1 or KBD2) in multi-panel configuration,
number of active CNC (between CN1 and CN4) in multi-CNC
configuration or system fault (PRSOV)
12 - Display unit: millimetres (mm) or inches (inch)
13 - End of part programme (M02), programmed stop (M00),
reset (momentary display of RESET) or current cycle (INCYC)
14 - Axis recall (AXRCL flashing) or manual override (INTER
flashing)
15 - Optional stop (M01) enabled
16 - Selected JOG increment (.001 to 10000, FREE or HANDWH)
17 - Standby mode
Special Case of the Compact Panel
The status window displayed on a compact panel is somewhat different from the standard status window:
- It includes a field indicating the name of the axis controlled by the jogs, followed by the group number in multigroup
systems
- It includes fields with indicators for the programmable function keys (lit if the function is active).
LOAD
MDI
100
TLCOMP
/
M01 INCYC CN1
MSGFDHLD
OVER
NC?? CYHLD
AXRCL
3
mm
X1 FCT
SFCT
1 2 3 4 5 6
1 2 3 4 5 6
2
1
N POS
1 - LEDs for the shifted programmable function keys
2 - LEDs for the programmable function keys
3 - Axis name followed by group number
