2.2 Switching on/off
2.2.1 Switching on
Switch on the machine using the procedure defined by the OEM
Example of equipment power up sequence:
- general switching on (the CNC and the peripherals),
- switching on the power systems (with conditions related to the CNC).
When the CNC is switched on, a status window displays the following type of information:
FREE M02 CN1
OVER
CAPS
HOME
12345
1 - Increment indicator: "FREE" is the default setting (another
increment can be selected by the PLC)
2 - "HOME" indicator: the measurement origin settings still to be
performed on the declared axes
3 - "M02" indicator: normal status of the system when not machining
(the "RESET" indicator is displayed if there is no PLC programme
or the PLC is faulty)
4 - "CN1" indicator: in single-panel configuration (single or multiple
CNC), the first CNC is the default CNC
5 - "OVER" and "CAPS" indicators: text editor is set to overtype
mode and upper case letters when the system is switched on
If one of these indicators is missing, a fault may be present on the system.
Notes
If the power to the CNC is switched off and back on, all the machining parameters (shifts, tool offsets, etc.) remain
stored; only the measurement origin is lost.
Incidents
Any message displayed when the CNC is switched on (See chapter 7) is linked to a system fault.
2.2.2 Restart Following an Emergency Stop
An emergency stop automatically switches off the power to the machine actuators. The CNC remains energised and
retains all the machining data including movement commands.
Reset all the current movement commands. ☞
Restart the machine using the procedure defined by the OEM.
