CNC Operation
en-938821/2 5 - 25
5
5.4 Automatic Programme Execution
5.4.1 Loading Programmes
Requirements
No mode being executed.
Actions
Select the 2nd page of Mode softkeys. ☞
MODE
MODE
Display of the 2nd page of softkeys at the bottom of the screen:
TL SET LOAD UNLOADSHIFTS
Select load mode. ☞
LOAD
Display of the "FILE LOADING" menu and the load mode indicator in the status window:
LOAD
1
FILE LOADING MENU
> 0 PROGRAMMES
1 TOOL OFFSETS
3 ACTIVE PROGRAMME SELECTION
4 COMMUNICATIONS
LINE ( ) : COMM1
1 - Serial line selected
To select an item, move the cursor onto the item with the up and down arrow keys or enter the item number then press
.
Selecting the serial line
The CNC serial line parameters must be set (see 8.3) according to the peripheral (See peripheral manual).
Set the peripheral transmission parameters.
Select the serial line set for the peripheral. ☞
➞
or
➞
The line selected is displayed.
